CUSH-800-ST-FLAT-72 CUSHMAN HAULER 800

The CUSH-800-ST-FLAT-72 refers to a specialized conversion of the Cushman Hauler 800 utility vehicle, transforming it into a heavy-duty flatbed cart. This modification is typically performed by aftermarket specialists like In Place Technology, which customizes the standard 2-seat Hauler 800 into a 6-foot flatbed utility vehicle.

Specifications

• Engine Options:

  • Gas Model: 13.5 hp (10.1 kW), 4-cycle, 24.5 cu in (401cc) engine with air cooling and pressurized oil system.

  • Electric Model: 11.7 hp (8.7 kW) peak, powered by a 56.7V ELiTE lithium battery system.

• Performance:

  • Top Speed: Up to 14.5 mph (23.3 kph) for gas models; up to 16.5 mph (26.5 kph) for electric models.

  • Towing Capacity: Up to 900 lbs (408.2 kg) with an optional rear hitch receiver.

• Dimensions:

  • Overall Length: 110 inches (280 cm)

  • Overall Width: 49 inches (125 cm)

  • Overall Height: 51 inches (129.5 cm) without canopy; 74 inches (188 cm) with canopy

  • Wheelbase: 65.5 inches (166.4 cm)

  • Ground Clearance: 4.3 inches (10.9 cm)

  • Outside Clearance Circle: 18.9 ft (5.8 m)

• Cargo Bed:

  • Standard Bed Capacity: 8.4 cu ft (0.24 m³) with a 400 lb (181.4 kg) load capacity.

  • Flatbed Conversion: 6-foot steel diamond plate flatbed with reinforced chassis, suitable for heavy-duty utility tasks.
